Ricochet Longitudinal Barrier
Ideal for events, construction and civil projects.
Product Overview
The Ricochet Longitudinal Barrier is the orange run-length module in the Ricochet MASH TL1 road safety barrier system. Each 2m unit is rotationally moulded from UV-stabilised polyethylene and filled on site with 600 litres of water to deliver certified containment of an errant vehicle at 50 km/h.
The system is tested to MASH standards using 1100 kg and 2270 kg vehicles at a 25° impact angle, with a deflection envelope of 2.28 metres. A compliant installation requires a minimum 45-metre run: at least 20 orange Longitudinal Barriers (40m) plus two yellow Terminal End units and a Terminal End Cap at each end.
Key Features
- MASH TL1 certified.
- Single module: 2m long x 0.58m wide x 1.03m high.
- 1.7m effective length per module when interlocked.
- 62 kg dry, 662 kg water-filled.
- 600L water-fill capacity per module, water only.
- Rotationally moulded UV-stabilised polyethylene in high-visibility orange.
- Deflection at 50 km/h impact: 2.28m.
- Cannot be accidentally interlocked with non-compliant barriers.
- 3-year manufacturer warranty.
System Components
- Ricochet Longitudinal Barrier (orange), this product, water-filled.
- Ricochet Terminal End (yellow), two units required at each end of the run; not water-filled.
- Ricochet Terminal End Cap Male and Female (yellow), one of each at each terminal; not water-filled.
- Ricochet Barrier Pin, one per barrier-to-barrier connection.
Installation Requirements
- Minimum compliant run: 45 metres total (20 orange Longitudinal + 2 yellow Terminal End + 1 Terminal End Cap each end).
- Maximum ground slope: 10% (1v:10h) across the install.
- Do not install on top of, behind, or in front of kerbs and channels without road-authority approval.
- Allow a 2.28m deflection zone clear of workers and equipment on the construction side.
Common Applications
- MASH-compliant traffic lane separation at road works.
- Worker and pedestrian protection alongside live roads up to 50 km/h.
- Construction zones adjacent to traffic.
- Event vehicle exclusion where road safety rating is required.
Technical Specifications
Summary
Specifications
Every product in the TFH range is tested to meet Australian safety standards.
